Specifications (B-2A Block 30)

B-2 Bomber

The B-2’s first public flight in 1989. Click image for larger view, then click that image for full size view.

What’s a B-2 Bomber doing on a travel quiz site? Because there are still a lot of secrets about it. This image appears elsewhere on the site (if you can find it) so this explains something about that image.

Data from USAF Fact Sheet, Pace, Spick

General characteristics

  • Crew: 2: pilot and commander (co-pilot)
  • Length: 69 ft (21.0 m)
  • Wingspan: 172 ft (52.4 m)
  • Height: 17 ft (5.18 m)
  • Wing area: 5,140 ft² (478 m²)
  • Empty weight: 158,000 lb (71,700 kg)
  • Loaded weight: 336,500 lb (152,200 kg)
  • Max. takeoff weight: 376,000 lb (170,600 kg)
  • Powerplant: 4 × General Electric F118-GE-100 non-afterburning turbofans, 17,300 lbf (77 kN) each
  • Fuel Capacity: 167,000 pounds (75,750 kg)



Performance

  • Maximum speed: Mach 0.95 (550 knots, 630 mph, 1,010 km/h) at 40,000 ft altitude / Mach 0.95 at sea level
  • Cruise speed: Mach 0.85 (487 knots, 560 mph, 900 km/h) at 40,000 ft altitude
  • Range: 6,000 nmi (11,100 km (6,900 mi))
  • Service ceiling: 50,000 ft (15,200 m)
  • Wing loading: 67.3 lb/ft² (329 kg/m²)
  • Thrust/weight: 0.205



Armament

  • • 2 internal bays for 50,000 lb (23,000 kg) of ordnance and payload
  • 80× 500 lb class bombs (Mk-82, GBU-38) mounted on Bomb Rack Assembly (BRA)
  • 36× 750 lb CBU class bombs on BRA
  • 16× 2000 lb class bombs (Mk-84, GBU-31) mounted on Rotary Launcher Assembly (RLA)
  • 16× B61 or B83 nuclear bombs on RLA (strategic mission)
